Fiberglass Mesh Fabric
Home / Product Pategory / Fiberglass Mesh Fabric
No. of Product Width (mm) Model of Raw Yam (tex)   Model of Raw Yam (tex)  Mesh (mm)  Mesh (mm)  Mesh (mesh/inch)  Mesh (mesh/inch)  Weave Resin Content (%) Weight (g/m 2) Fracture Strength (N/50mm)  Fracture Strength (N/50mm)
Warp Woof Warp Woof Warp Woof Warp Woof
1 1000-1250 32x2 204 5 5 5 ± 0.5 5 ± 0.5 union 20 ± 2 65 ± 3 500 500
2 1000-1250 50x2 255 5 5 5 ± 0.5 5 ± 0.5 union 18 ± 2 80 ± 3 800 900
3 1000-1250 100x2 306 5 5 5 ± 0.5 5 ± 0.5 union 18 ± 2 125 ± 3 1100 1300
4 1000-1250 134x2 357 5 5 5 ± 0.5 5 ± 0.5 union 18 ± 2 145 ± 3 1300 1500
5 1000-1250 134x2 408 5 5 5 ± 0.5 5 ± 0.5 union 18 ± 2 2160 ± 3 1500 1700
6 1000-1250 50x2 204 4 5 6 ± 0.5 5 ± 0.5 union 18 ± 2 80 ± 3 550 800
7 1000-1250 100x2 255 4 5 6 ± 0.5 5 ± 0.5 union 18 ± 2 110 ± 3 1100 1000
8 1000-1250 134x2 306 4 5 6 ± 0.5 5 ± 0.5 union 18 ± 2 150 ± 3 1400 1500
9 1000-1250 32x2 204 4 4 6 ± 0.5 6 ± 0.5 union 19 ± 2 80 ± 3 550 850
10 1000-1250 100x2 204 4 4 6 ± 0.5 6 ± 0.5 union 18 ± 2 120 ± 3 1100 900
11 1000-1250 134x2 255 4 4 6 ± 0.5 6 ± 0.5 union 18 ± 2 150 ± 3 1500 1600
12 1000-1250 134x2 306 4 4 6 ± 0.5 6 ± 0.5 union 18 ± 2 160 ± 3 1500 1800
13 1000-1250 50x2 306 5 6 5 ± 0.5 4 ± 0.5 union 18 ± 2 80 ± 3 500 1000
14 1000-1250 100x2 357 5 6 5 ± 0.5 4 ± 0.5 union 18 ± 2 110 ± 3 1000 1200
15 1000-1250 255x2 408 10 10 2.5 2.5 union 18 ± 2 220 ± 3 1000 1200
16 1000-1250 255x2 561 10 10 2.5 2.5 union 18 ± 2 125 ± 3 1000 1400
17 1000-1250 375x2 561 10 10 2.5 2.5 union 18 ± 2 145 ± 3 1400 1500
18 1000-1250 375x2 561 10 10 2.5 2.5 union 18 ± 2 160 ± 3 1500 1600
19 1000-1250 33x2 67 2.8 2.8 9 ± 0.5 9 ± 0.5 union 21 ± 2 45 ± 3 600 600

Fiberglass Mesh Fabric is a multifunctional engineering substrate made of woven glass fiber yarn with a special coating. Primarily used as a reinforcing framework, it is widely applied in wall crack prevention, waterproof membranes, underfloor heating systems, and GRC products, providing reliable tensile strength and dimensional stability. Its core performance characteristics lie in its excellent alkali resistance, temperature change resistance, and flexibility, effectively dispersing stress and preventing substrate cracking. This Fiberglass Mesh Fabric is non-flammable and corrosion-resistant, and exhibits good compatibility with various adhesives and mortars. Choosing high-quality Fiberglass Mesh Fabric is crucial for ensuring the long-term integrity and durability of engineering projects.

About
Zhejiang Yuanda Fiberglass Mesh Co.,ltd.
Zhejiang Yuanda Fiberglass Mesh Co.,ltd.

Zhejiang Yuanda Fiberglass Mesh Co., Ltd. was founded in 2000. It is a technology-oriented manufacturing enterprise focusing on the new materials field, specializing in the research and development and production of composite reinforcing materials, insulating materials, and related intelligent equipment. Committed to providing professional and reliable products and services to customers worldwide. The company is located in the Yangtze River Delta economic Circle of China, close to Ningbo Port and Shanghai Port. The unique geographical location has brought convenience to the company's import and export business. The company covers an area of nearly 33,000 square meters and has modern standard workshops.
The three core business segments
1. Composite material fiber bars and fiber bar mesh sheets (GFRP), as well as supporting production equipment.
2. Special interlayer insulating materials for power transformers and motors.
Iii. Alkali-resistant fiberglass mesh fabric and alkali-resistant emulsion for construction.

For the past 25 years, Zhejiang Yuanda Fiberglass Mesh Co., Ltd. has been deeply engaged in the field of new materials, deepening technological innovation and industrial collaboration, continuously expanding the application scope of its products, and has won wide recognition from customers. In the future, we will be committed to building a leading domestic supplier of composite new materials and injecting continuous impetus into the high-quality development of the industry.
